Description
Pair: ECC83 PhilipsMiniwatt f92 long plate; made in 1959 by Mullard UK.
Description
This is a pair ECC83 double triodes that are produced for Philips Miniwatt by Mullard in Blackburn UK. The tubes have a ring getter, copper grid posts and long plates (Version f92; introduced just after the mC-series), see pictures. Both tubes are manufactured in 1959. The tubes are NOS !; no signs of use at all. Very healthy tubes with NOS specs and excellent matching systems; see test results.
The tubes look and measure unused; see pictures!
Sonics
The early the long plate Mullard, is highly regarded; delivers space and transparency. I refer to the many threads on the web for more information. Excellent preamp valve, low noise, very smooth extended highs, very good in phono stages. Balanced and smooth sounding with liquid midrange, recommended!
Test results*
The measurement data below show that both systems are precisely matched and balanced. And fully in line with the factory specification for a NOS-tube.
| Valve 1
V96 |
Ia (plate current):
Transconductance (Gm): Gas test, Shorts test: |
1,3/ 1,3 mA
1,8/ 1,7 mA/V OK |
= NOS
= NOS |
| Valve 2
V234 |
Ia (plate current):
Transconductance (Gm): Gas test, Shorts test: |
1,2/ 1,1 mA
1,7/ 1,6 mA/V OK |
= NOS
= NOS
|
Where NOS is : Ia = 1,1 to 1,4mA, Gm= 1,3 to 1,95 mA/V.
* For test methods and factory specification read the tube testing page.
Short description
| Tube type | ECC83 |
| Quantity of Tubes | One pair |
| Brand | Philips Miniwatt |
| Manufactured | Mullard Blackburn UK |
| Dates | 1959 / 1959 (codes: f92 B 9C & f92 B 9F ) |
| Construction | Long ribbed plates, copper grid posts |
| Getter Construction | Halo getter |
| Print Condition | Both excellent; see pictures |
| Box included | Philips factory box |
| Equivalent tubes: | 12AX7, ECC803S, CV4004, 12AX7A, B339, 12AX7WA |
| General test results | NOS |
